Inspur NF5180M6 1U Rack Server Overview
Inspur NF5180M6 is a 1U 2-socket rack-mounted server for high-density computing
purposes. With the Xeon® Scalable processor design from the Intel® Whitley platform,
it maximizes the performance, density, and scalability of the server and adapts to
computing-intensive services such as virtualization, high-performance computing, and
online computing, meeting the deployment requirements of high-density data centers.
Features
Inspur NF5180M6 delivers high quality and reliability for all kinds of applications, as
Inspur servers always do. It features highly flexible configurations to cater to
mainstream market demands, providing extreme performance, scalability, availability,
and manageability at the same time.
Performance
NF5180M6 is built on the new third-generation Intel® Xeon® Scalable processors.Each CPU supports up to 40 cores running at the maximum processor frequency of3.6 GHz and up to 270 W thermal design power (TDP) with 3 Ultra PathInterconnect (UPI) links at 11.2 GT/s, enabling an increase in the overall computingperformance by 40%.
32 3200 MT/s DDR4 ECC RDIMM memory modules with each having a maximumcapacity of 128 G, adding up to 10 T to deliver a high read/write speed and highavailability.
3200 MHz Optane® Persistent Memory (PMEM) with a maximum capacity of 512G, using which data loss does not easily occur in case of power outage, whilememory capacity and bandwidth are not even reduced.
All-flash configuration of up to 12 hot-swap NVMe SSDs that provide a highinput/output operations per second (IOPS) solution ten times better than thatprovided by high-end enterprise-level SATA SSDs, with the storage capacityincreased by 20% compared to the previous generation.
All-flash configuration of up to 32 hot-swap E1.S SSDs that inherit the advantagesof traditional NVMe SSDs with a high IOPS and features a small footprint,implementing massive storage in 1U space and providing 3.2 times better overallIOPS performance.
